Product details

• Built-in continuous water softener (ATTENTION: cold water connection).
• Plate loading height Ø 390mm (glass height 355 mm).
• From 30 to 20 baskets/hour. 120", 180", continuous and "Sanitisation" PLD cycles.
• 3 phases: washing, discharging, rinsing.
• Drain pump as standard.
• Standard rinsing pump (atmospheric boiler).

• Realization: fully manufactured in stainless steel AISI 304. Rotating wash and rinse arm (composite). Tank's filter (composite) (15L - 1,4kW). Moulded polypropylene wash chamber, with external pipes. Pump filter in polypropylene. Wash pump (double flux) 0,63 Hp (230V/1). Double-walled pressed door, smooth open/close system thanks to counter balancing, waterproof sealed door, stamped door handle. Adjustable stainless steel feet. Removable control panel for easy maintenance.
• Tank with automatic refill. Non-return valve. Hot water rinse (water consumption per cycle 2,7L), stainless steel boiler (6L - 7,6kW). Possibility to regulate the tank and boiler's temperature. Microswitch, to stop the cycle when the door is opened. Safety thermostat. Standard: 2 baskets, 1 beaker, connection for the water pipe and drainage.

The +

ADVANTAGE - SANITISATION:
This new sanitation program offers an additional guarantee thanks to a thermal disinfection phase during which the dishes are heated to a temperature of over 70°C and left there for a sufficient amount of time to reach an A0 lethality index of over 30 (sanitary standard EN 15883). This standard guarantees the elimination of certain classes of germs and bacteria. This "A0" value can be set as required and the cycle time is automatically adjusted accordingly. The level of hygiene achieved with this cycle is therefore far superior than that what a traditional washing cycle can offer.

ADVANTAGE - BREAK TANK :
The "break tank" is an anti-pollution device, AB type (UK standards). 1) It prevents that the tank water (with detergent) from flowing back to the distribution system. 2) Throughout the rinsing process, its pump guarantees a constant pressure, while drying and hygiene are ensured by a T° of 85°C...until the last drop of water!

ADVANTAGE - SAVE THE PLANET :
Latest-generation machines, cutting-edge technologies, energy-saving, low consumption of water and detergent, thanks to the tank with a larger capacity and its "patented" filter to keep the washing water at the right temperature , as well as a high-efficiency wash pump (double flow).

ADVANTAGE - Continuous Water Softener :
The built-in continuous water softener, constantly keeps softened water, regardless of the number of wash cycles, for perfect results. Offers the advantage of not having to stop the dishwasher to allow the regeneration of resins during the micro-interruptions wash cycle used to regenerate the resins, while continuing to wash!

PLUS:

• Peristaltic dispenser for rinsing product and peristaltic dispenser for liquid detergent supplied as standard.
• CSD digital control panel (soft touch).
• EED energy saver.
• TCD control thermostat for guaranteed rinsing at 85°C.
• DRD accelerated pre-heating phase.
• DID self-diagnosis in the event of a fault.
• ADD tank and boiler temperature display (HACCP standard).
• DDD partial tank emptying, evacuation through the bottom of the tank.
• CID ‘soft contact’ automatic closing door (partial opening to evacuate steam).
• RGD rinsing at constant temperature (85°C), stable pressure.
• BTD "Break Tank", anti-pollution device, AB type.
• CAD self-cleaning cycle (100% automatic).
• NB: machines guaranteed for use with ‘osmosis’ treated water supply.
